© Freescale Semiconductor, Inc., 2004, 2005, 2006. All rights reserved.
Freescale Semiconductor
Data Sheet: Technical Data
Freescale reserves the right to change the detail specifications as may be required to permit improvements in the design of its
products.
Document Number: MC9328MX1
Rev. 7, 12/2006
MC9328MX1
Package Information
Plastic Package
Case 1304B-01
(MAPBGA–225)
Ordering Information
See Ta bl e 1 on page 3
MC9328MX1
1 Introduction
The i.MX Family of applications processors provides a
leap in performance with an ARM9™ microprocessor
core and highly integrated system functions. The i.MX
family specifically addresses the requirements of the
personal, portable product market by providing
intelligent integrated peripherals, an advanced processor
core, and power management capabilities.
The MC9328MX1 (i.MX1) processor features the
advanced and power-efficient ARM920T™ core that
operates at speeds up to 200 MHz. Integrated modules,
which include a USB device, an LCD controller, and an
MMC/SD host controller, support a suite of peripherals
to enhance portable products seeking to provide a rich
multimedia experience. It is packaged in a 256-contact
Mold Array Process-Ball Grid Array (MAPBGA).
Figure 1 shows the functional block diagram of the
i.MX1 processor.
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 Signals and Connections . . . . . . . . . . . . . . . 4
3 Electrical Characteristics . . . . . . . . . . . . . . 22
4 Functional Description and Application
Information . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5 Pin-Out and Package Information . . . . . . . . 96
6 Product Documentation . . . . . . . . . . . . . . . . 98
Contact Information . . . . . . . . . . . . . . . Last Page
