© Semiconductor Components Industries, LLC, 2016
July, 2016 − Rev. 5
1 Publication Order Number:
MC100LVEL01/D
MC100LVEL01
3.3 V ECL 4-Input OR/NOR
Description
The MC100LVEL01 is a 4-input OR/NOR gate. The device is
functionally equivalent to the EL01 device and works from a 3.3 V
supply. With AC performance similar to the EL01 device, the LVEL01
is ideal for low voltage applications which require the ultimate in
AC performance.
Features
• 370 ps Propagation Delay
• High Bandwidth Output Transitions
• ESD Protection:
♦ > 2 kV Human Body Model
♦ > 200 V Machine Model
• The 100 Series Contains Temperature Compensation
• PECL Mode Operating Range: V
CC
= 3.0 V to 3.8 V
with V
EE
= 0 V
• NECL Mode Operating Range: V
CC
= 0 V
with V
EE
= −3.0 V to −3.8 V
• Internal Input Pulldown Resistors
• Q Output will Default LOW with All Inputs Open or at V
EE
• Meets or Exceeds JEDEC Spec EIA/JESD78 IC Latchup Test
• Moisture Sensitivity
♦ Level 1 for SOIC−8
♦ Level 3 for TSSOP−8
♦ For Additional Information, see Application Note AND8003/D
• Flammability Rating: UL 94 V−0 @ 0.125 in,
Oxygen Index 28 to 34
• Transistor Count = 83 Devices
• These Devices are Pb-Free and are RoHS Compliant
TSSOP−8
DT SUFFIX
CASE 948R
SOIC−8
D SUFFIX
CASE 751
*For additional marking information, refer to
Application Note AND8002/D
.
MARKING DIAGRAMS*
KV01
ALYWG
G
1
8
1
8
1
8
www.onsemi.com
KVL01
ALYW
G
1
8
A = Assembly Location
L = Wafer Lot
Y = Year
W = Work Week
M
= Date Code
G = Pb-Free Package
(Note: Microdot may be in either location)
SOIC−8 TSSOP−8
Device Package Shipping†
ORDERING INFORMATION
MC100LVEL01DG SOIC−8
(Pb-Free)
98 Units / Tube
MC100LVEL01DR2G SOIC−8
(Pb-Free)
2500
Tape & Reel
†For information on tape and reel specifications, in-
cluding part orientation and tape sizes, please refer
to our Tape and Reel Packaging Specifications
Brochure, BRD8011/D
.
TSSOP−8
(Pb-Free)
MC100LVEL01DTG
100 Units / Tube
