1/34February 2003
M25P10-A
1 Mbit, Low Voltage, Serial Flash Memory
With 25 MHz SPI Bus Interface
FEATURES SUMMARY
■ 1 Mbit of Flash Memory
■ Page Program (up to 256 Bytes) in 1.5ms
(typical)
■ Sector Erase (256 Kbit) in 2 s (typical)
■ Bulk Erase (1 Mbit) in 3 s (typical)
■ 2.7 V to 3.6 V Single Supply Voltage
■ SPI Bus Compatible Serial Interface
■ 25 MHz Clock Rate (maximum)
■ Deep Power-down Mode 1 µA (typical)
■ Electronic Signature (10h)
■ More than 100,000 Erase/Program Cycles per
Sector
■ More than 20 Year Data Retention
Figure 1. Packages
ENHANCED VERSION OF THE M25P10
This device is an enhanced version of the
M25P10. The enhanced features include: larger
page size, shorter programming time, higher clock
frequency.
SO8 (MN)
150 mil width
8
1
VFQFPN8 (MP)
(MLP8)
