Semiconductor Components Industries, LLC, 2013
December, 2013
http://onsemi.com
LV8712T/LV8713T
Overview
The LV8712T and LV8713T are micro-stepping motor drivers with built-in translator for easy operation.
The LV8712T supports full-step, half-step, quarter-step, and 1/8-step resolution. The LV8713T supports
full-step, half-step, 1/16-step, and 1/32-step resolution. These ICs are optimal for driving stepping motor of
scanner and small printer.
Function
Single-channel PWM constant-current control stepping motor driver incorporated.
Microstepping is configurable to the following modes:
Full-step, half-step, quarter-step, or 1/8-step. (LV8712T)
Full-step, half-step, 1/16-step, or 1/32-step. (LV8713T)
CLK-IN input facilitates the control of microstepping.
Power-supply voltage of motor : VM max = 18V
Output current : I
O
max = 0.8A
Output ON resistance : R
ON
= 1.1 (upper and lower total, typical, Ta = 25C)
Thermal shutdown circuit and low voltage detecting circuit incorporated.
Typical Applications
POS Printer
Scanner
Thermal Printer Unit
Security camera
Air-conditioner
Selection Guide
Part Number Microstepping mode
LV8712T Full-,half-,quarter-,1/8-step
LV8713T Full-,half-,1/16-,1/32-step
Bi-CMOS LSI
PWM Constant-Current Control
Stepper Motor Driver
Application Note
