Semiconductor Components Industries, LLC, 2013
December, 2013
http://onsemi.com
LV8711T
Overview
The LV8711T is a PWM constant-current control stepper motor driver which is low consumption, low heat
and high efficiency. The device is suited 2-cell battery applications. Its supply voltage range is from 4V to 16V,
and stand-by mode current drain is almost zero. It can contribute to reduce costs and PCB size because of
the built-in circuit to control current. It also can contribute to safe design of applications by several built-in
protection functions.
Function
Two circuits of PWM constant-current control H-bridge drivers incorporated
Control of the stepper motor to Half-step excitations possible
Reference voltage output: 1.0V
Short circuit protection circuit incorporated
Abnormal condition warning output pin incorporated
Upper and lower regenerative diodes incorporated
Thermal shutdown circuit incorporated
V
CC
Low Voltage Shut Down circuit incorporated
Typical Applications
POS Printer
Handy Type Scanner
Thermal Printer Unit
Card terminal
Air-conditioner
Bi-CMOS LSI
PWM Constant-Current Control
Stepper Motor Driver
Application Note
