1. General description
The LPC2101/2102/2103 microcontrollers are based on a 16-bit/32-bit ARM7TDMI-S
CPU with real-time emulation that combines the microcontroller with 8 kB, 16 kB or 32 kB
of embedded high-speed flash memory. A 128-bit wide memory interface and a unique
accelerator architecture enable 32-bit code execution at the maximum clock rate. For
critical performance in interrupt service routines and DSP algorithms, this increases
performance up to 30 % over Thumb mode. For critical code size applications, the
alternative 16-bit Thumb mode reduces code by more than 30 % with minimal
performance penalty.
Due to their tiny size and low power consumption, the LPC2101/2102/2103 are ideal for
applications where miniaturization is a key requirement. A blend of serial communications
interfaces ranging from multiple UARTs, SPI to SSP and two I
2
C-buses, combined with
on-chip SRAM of 2 kB/4 kB/8 kB, make these devices very well suited for communication
gateways and protocol converters. The superior performance also makes these devices
suitable for use as math coprocessors. Various 32-bit and 16-bit timers, an improved
10-bit ADC, PWM features through output match on all timers, and 32 fast GPIO lines with
up to nine edge or level sensitive external interrupt pins make these microcontrollers
particularly suitable for industrial control and medical systems.
2. Features
2.1 Key features
■ 16-bit/32-bit ARM7TDMI-S microcontroller in a tiny LQFP48 package.
■ 2 kB/4 kB/8 kB of on-chip static RAM and 8 kB/16 kB/32 kB of on-chip flash program
memory. 128-bit wide interface/accelerator enables high-speed 70 MHz operation.
■ ISP/IAP via on-chip bootloader software. Single flash sector or full chip erase in
100 ms and programming of 256 bytes in 1 ms.
■ EmbeddedICE RT offers real-time debugging with the on-chip RealMonitor software.
■ The 10-bit A/D converter provides eight analog inputs, with conversion times as low as
2.44 µs per channel and dedicated result registers to minimize interrupt overhead.
■ Two 32-bit timers/external event counters with combined seven capture and seven
compare channels.
■ Two 16-bit timers/external event counters with combined three capture and seven
compare channels.
■ Low power Real-Time Clock (RTC) with independent power and dedicated 32 kHz
clock input.
■ Multiple serial interfaces including two UARTs (16C550), two Fast I
2
C-buses
(400 kbit/s), SPI and SSP with buffering and variable data length capabilities.
LPC2101/2102/2103
Single-chip 16-bit/32-bit microcontrollers; 8 kB/16 kB/32 kB
flash with ISP/IAP, fast ports and 10-bit ADC
Rev. 01 — 18 January 2006 Preliminary data sheet
