SPEC NO: KDA0019 REV NO: V.1 DATE: SEP/04/2001 PAGE: 1 OF4
APPROVED: CHECKED: DRAWN: S. H. CHEN
Description
The Hyper Red source color devices are made with
DH InGaAlP on GaAs substrate Light Emitting Diode.
1.6x0.8mm SMD CHIP LED LAMP
KP-1608SURC HYPER RED
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is ±0.1(0.004") unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
Package Dimensions
Features
!1.6mmx0.8mm SMT LED, 1.1mm THICKNESS.
!LOW POWER CONSUMPTION.
!WIDE VIEWING ANGLE.
!IDEAL FOR BACKLIGHT AND INDICATOR.
!VARIOUS COLORS AND LENS TYPES AVAILABLE.
!PACKAGE : 2000PCS / REEL.
