SMT Trimmer Potentiometers/EVM2T/2N/2W
Design and specifi cations are each subject to change without notice. Ask factory for the current technical specifi cations before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
E
V
M
2N XS
0825
B
Product Code Packaging Taper & Resistance
Example : B52=500 액
✽For part number details, refer to page ER115.
12345
6
789101112
Type/Structure
(2T, 2N, 2W)
■ Recommended Applications
● Audio/visual, offi ce, and communication equipment
● General electronic equipment
2 mm Square Low-Profi le SMT Trimmer
Potentiometers
(Cermet, Open Frame Type)
Type:
EVM2T
EVM2N
EVM2W
■ Features
● Low-profi le
0.7 mm (0.75 mm max.) EVM2T
0.81 mm (0.95 mm max.) EVM2N
1.05 mm (1.2 mm max.) EVM2W
● Automatic adjustment type (EVM2W)
● High reliability realized by cermet element
● Ex cellent mountability
● Conforms to JIS C5260-1:1999
■ Explanation of Part Numbers
■ Specifi cations
■ Minimum Quantity/Packing Unit
Part Number
Taping
Quantity per reel Packaging quantity
Dia. of reel
(mm)
EVM2T
EVM2N
EVM2W
3000 15000
φ
178
Total Resistance Value
Resistance Tolerance
100
액
to 1 M
액
±25 %
Power Rating
Limiting Element Voltage(Maximum RCWV)
0.15 W
50 V
Rotation Torque
EVM2T, EVM2N : 0.5 to 10 mN·m
EVM2W : 1 to 15 mN·m
Temperature Coeffi cient of Resistance ±250
҂
10
–6
/°C(ppm/°C)
The standard packaging methods for a reel is
φ
178.
Please contact us, if you would like different packaging methods. (Bulk, Reel of
φ
330, Reel of
φ
380)
2T 2N 2W
Sep. 2009
