Thick Film Chip Resistors
MCR Series < Not for Automotive application >
www.rohm.com
○
c
2015 ROHM Co., Ltd. All rights reserved.
2015.02 - Rev.F
Da
t
asheet
Features
1) Full line up from ultra small size (01005) to 2512 with jumper type.
2) ROHM resistors have obtained ISO9001/ISO/TS16949 certification.
Packing
Specification
Quantity / Reel
Type Code
0603
1005
1608
2012
3216
3225
5025
6432
YRT 15,000
10,000
5,000
4,000
MRT
ERT
JRT
MCR006
MCR01
MCR03
MCR10
MCR18
MCR25
MCR50
MCR100
Paper tape
(4mm pitch)
Paper tape
(2mm pitch)
Embossed tape
(4mm pitch)
Part No.
(mm)
Size
0201
0402
0603
0805
1206
1210
2010
2512
(inch)
Part Number Description
06
MCR
(Micro chip resistors)
0YTR
CMR
Part No.
Resistance code, 3 or 4 digits.
000 denotes jumper type.
Ex.)
1Ω = 1R0 ( ±5% )
9.1 Ω = 9R1 ( ±5%
)
10 Ω = 10R0 ( ±0.5%,±1% )
100 ( ±5% )
2.2M Ω = 2204 ( ±1% )
225 ( ±5% )
D,F
J
:
:
4 digits
3 digits
Resistance
tolerance
Resistance
code
006 (0603 [0201])
01 (1005 [0402])
03 (1608 [0603])
10 (2012 [0805])
18 (3216 [1206])
25 (3225 [1210])
50 (5025 [2010])
100 (6432 [2512])
D ( ±0.5% )
F ( ±1% )
J ( ±5% )
(Including jumper type)
Size
(mm [inch])
Resistance Tolerance Nominal Resistance
J010
Type Code
