Plastic Film Capacitors
Design, Specifications are subject to change without notice. Ask factory for technical specifications before purchase and/or use.
Whenever a doubt about safety arises from this product, please inform us immediately for technical consultation without fail.
Film Chip Capacitor
Type:
ECHU(C)
Stacked metallized PPS film as dielectric with simple
mold-less construction
■Features
●Small in size
●Low loss and excellent frequency characteristics
■Recommended Applications
●Time-constant
●Filtering
●
Oscillation and resonance
●
Resonance circuit for LCD backlighting inverter unit
■Explanation of Numbers
■Specification
50VDC:-55 to +125 ℃
Category temp. range
100VDC: -55 to +105 ℃
Rated voltage
50VDC
(0.12µF or more:Derating of rated voltage by 1.25%/℃ at more than 105℃) ,
100VDC
50VDC 0.047 to 0.22µF (E12)
Capacitance range
100VDC 0.01 to 0.22µF (E12)
Capacitance tolerance ±2%(G),±5%(J)
Withstand voltage
50VDC:Between terminals : Rated volt. (VDC)×175% 1 to 5s
100VDC:Between terminals : Rated volt. (VDC)×160% 60s
Dissipation factor
0.6% or less (20℃,1kHz)
Insulation resistance
50VDC:3000MΩ or more (20℃, 50VDC,60s)
100VDC: 3000MΩ or more (20℃, 100VDC,60s)
50VDC
Flow soldering:260℃ max.,5s max.
Reflow soldering:260℃ max. and 30 s max. at more than 230℃
(Temp. at cap. Surface)
Soldering conditions
100VDC
Reflow soldering:260℃ max. and 30 s max. at more than 230℃
(Temp. at cap. Surface)
Dielectric &
construction
Product code
Rated voltage Capacitance
Cap. Tol. Suffix
E C H U C
1 2
3
4 5 6 7 8 9 10 11 12
Tape width
912mm
V16mm
Suffix
G
±2％
J
±5％
1H 50VDC
1 100VDC
