Freescale Semiconductor SLK0106AN
Application Note Rev. 0, 1/2007
© Freescale Semiconductor, Inc., 2006. All rights reserved.
_______________________________________________________________________
Interfacing AP13192USLK with Microcontroller Student
Learning Kits
By: Juan Czares Blanco
RTAC AMERICAS
1 Introduction
This document guides you through the steps
necessary to begin development with the
AP13192USLK Radio Frequency (RF)
transceiver, Freescale Project Board, and select
Student Learning Kits (or equivalent
microcontroller evaluation boards).
The hardware setup section will walk you
through configuring the RF-Transceiver, project
board, application module. The software setup
section assists you in running a demonstration
wireless UART application. This application
uses SMAC protocol and includes all necessary
CodeWarrior project files.
Refer to the project board user guide,
application module user guide, and
CodeWarrior documentation available at
www.freescale.com\universityprogram for
additional resources.
Contents
1 Introduction.................................................... 1
2 Naming Conventions ..................................... 2
3 Software Setup............................................... 2
4 Hardware Setup.............................................. 3
4.1 Configuring the AP13192USLK Board.. 3
4.2 Defining Test Mode Buttons................... 4
4.3 Configuring the Freescale MCU Project
Board............................................................. 5
4.4 Connections between APS08QG8SLK
and AP13192USLK boards........................... 6
4.5 Connections between APS12D board(s)
and AP13192USLK board.......................... 11
4.6 Connections between APS12C32 board
and AP13192USLK board.......................... 14
Applicable part numbers:
[PB/AP/CSM9]S08QG8SLK
DEMO9S08QG8
[PB/AP/CSM9]S12C32SLK
[PB/AP/CSM9]S12DT256SLK
[PB/AP/CSM9]S12XDT512SLK
