Powering the AD9788 800 MSPS TxDAC Digital-to-Analog Converter Using
the ADP2105 Synchronous Step-Down DC-to-DC Regulator for Increased Efficiency
Rev. A | Page 1 of 3
CIRCUIT FUNCTION AND BENEFITS
This circuit utilizes a pair of ADP2105 synchronous step-down
dc-to-dc regulators to provide the individual power supply rails
required for the AD9788 dual channel, 16-bit, high dynamic
range TxDAC® digital-to-analog converter. The ADP2105 pair
powers the AD9788 at greater than 85% efficiency, which is up
to 50% higher than that obtained using a traditional linear
regulator solution. Total circuit power dissipation using linear
regulators is 1.4 W and using switching regulators only 0.88 W.
This increased efficiency results in lower system level power
consumption, with no measurable degradation in the perfor-
mance of the AD9788. The ADP2105 is low noise step-down
dc-to-dc converter that uses a fixed frequency, peak current
mode architecture with an integrated high-side switch and
low-side synchronous rectifier. The high 1.2 MHz switching
frequency allows the use of small external inductors and
ceramic capacitors; and the tiny 16-lead, 4 mm × 4 mm
LFCSP_VQ package minimizes PCB area.
The AD9788 supports DAC update rates to 800 MSPS. The low
noise and excellent linearity of the AD9788 enable transmit
architectures from baseband to complex IF frequencies up to
200 MHz. The AD9788 features a rich set of digital signal
processing, including 2×, 4×, and 8× interpolation filter options
and complex digital modulation with a 32-bit NCO resolution,
as well as gain, phase, and offset compensation. The DAC
outputs interface seamlessly with analog quadrature
modulators, such as the ADL537x family.
CIRCUIT DESCRIPTION
Table 1. Devices Connected/Referenced
Product Description
AD9788
Dual, 16-Bit, 800 MSPS TxDAC® digital-to-analog
converter with low power 32-bit complex NCO
ADP2105 1 A, synchronous, step-down DC-to-DC converter
Figure 1 shows the ADP2105 power supply solution, which
supplies the necessary input power rails to the AD9788 DAC.
The AD9788 has four power domains: two that require 3.3 V
and two that require 1.8 V. The two domains at 3.3 V are
DVDD33, which supplies the I/O circuits, and AVDD33, which
supplies the DAC internal switch core. The two domains at
1.8 V are DVDD18, which supplies the digital processing
circuitry, and CLKVDD18, which supplies the clock receiver
and PLL circuitry. The domains requiring 3.3 V are supplied by
a single ADP2105 (3.3 V) device, and the domains requiring 1.8 V
are supplied by a single ADP2105 (1.8 V) device.
The power domains of each rail are isolated from each other by
use of a ferrite bead, as shown in Figure 1. One bulk capacitor
per domain, plus localized high frequency decoupling capaci-
tors on individual supply pins, provide adequate bypassing to
preserve the dynamic performance of the AD9788. The input
voltage to the ADP2105 impacts the size of the required
inductor and also affects the efficiency of the regulator. Lower
input voltages generally require smaller inductors and improve
the power supply efficiency. The configuration shown uses a
3.3 V input rail to supply the 1.8 V regulator and a 5.0 V input
rail to supply the 3.3 V regulator.
Figure 2 shows a representative comparison of the spectral plots
from the AD9788 when powered from linear regulators versus
the ADP2105 switching regulators. The particular instance
shown is for DAC output frequency, F
OUT
= 125 MHz, DAC
input data rate, F
DATA
= 200 MHz, and 4× interpolation. Under
these conditions, the DAC outputs a 125 MHz signal at an
800 MSPS update rate. The output spectrum of the AD9788
shows no measurable increase in noise floor or spurs associated
with the switching frequency under the test cases considered.
The efficiency results in Table 1 compare the overall efficiency
of an LDO regulator design to the ADP2105 based switching
regulator design. The linear regulators and the switching regulators
used the same input voltages. The 1.8 V regulators were supplied
with 3.3 V input rails. The 3.3 V regulators were supplied with
5.0 V input rails. The use of switching regulators resulted in
power savings of 457 mW and an efficiency gain in overall
power consumption of about 50%.
Proper component placement, power and ground plane layout,
and signal routing are critical to a successful design when using
a dc-to-dc regulator, such as the ADP2105. Adhering to the
detailed layout guidelines in the switching regulator data sheet
should lead to a successful application of the device. These
guidelines usually call for switching inductors to be mounted
far away from the DAC and sensitive components in the DAC’s
clock and signal paths—or on the opposite side of the PCB to
help eliminate magnetic flux coupling into sensitive compo-
nents. High current loops should be kept as short as possible.
Bypass capacitors and compensation networks for the regulators
should be placed close to the device.
