Jun-29-2004
1
BAS40.../BAS140W
Silicon Schottky Diode
• General-purpose diode for high-speed switching
• Circuit protection
• Voltage clamping
• High-level detecting and mixing
BAS140W
BAS40-02L
BAS40-06
BAS40-06W
BAS40 BAS40-05
BAS40-05W
BAS40-04
1 2
3
1
D 2
2
D 1
3
1
D 2
2
D 1
3
1 2
3
1
D 2
2
D 1
BAS40-07
1
D 2
2
34
D 1
ESD: Electrostatic discharge sensitive device, observe handling precaution!
Type Package Configuration L
S
(nH) Marking
BAS140W
BAS40
BAS40-02L*
BAS40-04
BAS40-05
BAS40-05W
BAS40-06
BAS40-06W
BAS40-07
SOD323
SOT23
TSLP-2-1
SOT23
SOT23
SOT323
SOT23
SOT323
SOT143
single
single
single, leadless
series
common cathode
common cathode
common anode
common anode
parallel pair
1.8
1.8
0.4
1.8
1.8
1.4
1.8
1.4
2
white 4
43s
FF
44s
45s
45s
46s
46s
47s
*Preliminary
