AL1696
Document number: DS38304 Rev. 1 - 2
1 of 14
www.diodes.com
October 2015
© Diodes Incorporated
NEW PROD U C T
AL1696
HIGHLY INTEGRATION OFFLINE DIMMABLE LED DRIVER
Description
The AL1696 is a highly integrated high power factor constant current
converter for mains dimmable LED driver applications. The AL1696
controls the system operating in boundary conduction mode (BCM) to
ease in EMI/EMC qualification and testing to meet the latest
regulatory standards.
The AL1696 with build-in MOSFET solution reduces the bill of
material (BOM) cost by eliminating the need of auxiliary winding and
external high voltage MOSFET.
The AL1696 can be compatible with a wide range of dimmers
including leading edge and trailing edge dimmers. Some dimmers can
achieve deep dimming down to 1%. The AL1696 dimming curve is
compliant with the standard of NEMA SSL6.
The AL1696 is available in SO-7 package, which provides an extra
pin spacing between the high voltage MOSFET’s drain and low
voltage pins to increase electricity isolation.
Features
Internal MOSFET up to 300V/3A, 500V/2A, 600V/2A
Tight Current Sense Tolerance: ±3%
Low Startup Current: 150µA
Low Operation Current: 120µA (Switching Frequency at 5kHz)
Single Winding Inductor
Wide Range of Dimmer Compatibility
Dimming Curve Compliant with NEMA SSL6
Internal Protections
Under Voltage Lockout (UVLO)
Leading-Edge Blanking (LEB)
Cycle-by-cycle Over Current Protection (OCP)
Output Short Protection (OSP)
Over-Temperature Protection (OTP)
SO-7 Package
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Pin Assignments
(Top View)
1
2
3
4
7
6
5
GND
CS
NC
NC
RT
D
VCC
SO-7
Applications
Mains Dimmable LED Lamps
Offline LED Power Supply Driver
Notes: 1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
